Stainless Steel Spring Roll Sheet Lumpia Wrapper Production Line

  • Brand:GELGOOG
  • Capacity:500-9000pcs/h
  • WhatsApp: 008618537181190

Features

The Stainless Steel Spring Roll Sheet Production Line is made of Stainless Steel; it uses flour as material, you also can addsome spice to make spring roll sheet. Operation is very easy and has high capacity! It can make round or rectangular(need Cutting Part) spring roll sheet. We can make new machines according to your sheet diameter.
GELGOOG also offer Spring Roll Making Machine

spring roll wrapper making machine
Process of the  automatic spring roll wrapper making machine:
After the baking wheel is heated, the pulp is heated, the slurry is moved to the nozzle, and the clutch operating rod is operated to make the slurry adhere to the arc surface of the roast wheel. When the roast wheel is rotated, the pulp is cured and separated automatically from the roast wheel to form a fixed thickness spring roll or the roll of spring rolls immediately. The heating way of the baking wheel is divided into electric heating and gas heating, which are for users to choose.

spring roll wrapper production line
Working Process of spring roll wrapper production line:
1. According to different spring roll skin recipes, mix flour, water and other materials in a certain ratio;
2. Pour the batter evenly into the storage tank, and the machine can extract the batter onto the baking wheel.
3. After turning the baking wheel and turning to a 270 degree, the spring roll wrapper can be baked and formed;
4. The conveyor belt transports the summer roll sheet and then is cooled by the fan.
5. The automatic spring roll wrappers making machine cuts the whole sheet into spring roll wrappers of equal size.

Video:

Technical Data

Model GG-3620 GG-5029 GG-8045 GG-12060
Voltage 380/220V(50/60HZ) 380/220V(50/60HZ) 380/220V(50/60HZ) 380/220V(50/60HZ)
Dia. of heating Cylinder 400mm 500mm 800mm 1200mm
Power 8/10kw or gas 18kw or gas 40kw or gas 59kw or gas
Host Power 0.4 0.4 0.4 0.75
Cutter Power 0.2 0.2 0.2 0.2
Belt power - 0.36 0.36 0.55
Capacity
(Sheet Dia/Width 150mm)
500-1000pcs/h 1000-1500pcs/h 3500pcs/h 9000pcs/h
Dimension 4100*950*1350mm 5200*950*1350mm 6200*1100*1600mm 6500*1300*2300mm
Rotating speed 1-2.5r/min 1-2.5r/min 1-3r/min 1-3r/min
Weight 330kg 520kg 1000kg 1750kg
Size of the Sheet ( Max.) 200mm 300mm 450mm 600mm
Thickness of the Sheet 0.3-2.0mm 0.3-2.0mm 0.3-2.0mm 0.3-2.0mm
